Products Description
- High-Performance Lithium-Ion Battery Pack:
- Equipped with a lithium-ion battery pack, this system providing ample power storage for your daily needs.
- Lithium-ion batteries offer superior energy density, long cycle life, and fast charging capabilities, ensuring reliable backup power when needed.
- Integrated MPPT Solar Charge Controller:
- The built-in Maximum Power Point Tracking (MPPT) solar charge controller optimizes energy harvesting from your solar panels.
- It intelligently adjusts to the solar array's optimal operating point, maximizing the amount of solar energy converted into battery storage.
- On-Grid Capability:
- The system seamlessly integrates with your home's electrical grid, allowing you to use grid power when available and switch to battery power during outages.
- IP65 Waterproof Enclosure:
- Designed with IP65 waterproof protection, the system can withstand harsh outdoor conditions, ensuring reliable operation in all weather.
- Perfect for installation on balconies, patios, or other outdoor areas.
- Smart Energy Management System:
- The integrated smart energy management system monitors your energy usage.
- It allows you to monitor your energy consumption, control your devices remotely.
- Easy Installation & Maintenance:
- The system comes with a user-friendly installation guide and all necessary accessories, making setup a breeze.
- Easy for Maintenance durable components and intuitive user interface.
Technical parameter
| No. | Item | Parameters |
| 1 | Model | ELT800-B |
| PV Input | ||
| 2 | Input voltage range | 10-60V DC |
| 3 | MPPT number | 1 |
| 4 | MPPT power | 600W |
| 5 | Conversion efficiency | 0.96 |
| AC Output | ||
| 6 | Rated output power | 800W |
| 7 | Max. output power | 960W |
| 8 | Rated output voltage | 220/230/240V AC |
| 9 | Output voltage range | 190-270VAC |
| 10 | Rated output current | 3.6A |
| 11 | Rated frequency | 50/60Hz |
| 12 | Max. conversion efficiency | 0.965 |
| Battery | ||
| 13 | Nominal Voltage | 51.2V |
| 14 | Rated Capacity | 27Ah |
| 15 | Nominal Energy | 1.382KVVh |
| 16 | Battery Type | LiFePO4 |
| 17 | CycleLife | >6000 times [Standard discharge(0.2 C›) after standard charge(0.2 C )] |
| General | ||
| 18 | Waterproof class | IP65 |
| 19 | Cooling method | Natural cooling |
| 20 | Communication port | Wi-Fi |
| 21 | On-grid certificate | EN61000-3-2, EN61000-3-3, EN62109-2, EN55032, EN55035,EN50438 |
| 22 | Operation Temperature Range | -20—65°C |
| 23 | Dimensions | 500*390*l70mm (excluding terminals, carrying handle) |
| 24 | Weight | 30kg |
